SPECIFICATION
- DC voltage
Maximum Voltage: 1000V
Accuracy: Fluke 87 V: ± (0,05%+1)
Maximum resolution: Fluke 87 V: 10 μV
- AC Voltage
Maximum Voltage: 1000V
Accuracy: Fluke 87 V: ±(0.7%+2) practical effect
Maximum resolution: 0.1 mV
- DC current
Maximum amperage: 10A (up to 20 A in 30 seconds)
Accuracy of amperage: Fluke 87 V: ±(0,2%+2)
Maximum resolution: Fluke 87 V: 0.01 μA
- AC current:
Maximum amperage: 10A (up to 20 A in 30 seconds)
Accuracy of amperage: Fluke 87 V: ±(1.0%+2) practical effect
Maximum resolution: 0.1 μA
- Electrical resistance
Maximum resistance: 50 MΩ
Accuracy: Fluke 87 V: ±(0,2%+1)
Maximum resolution: 0,1Ω
- Capacitance
Maximum capacitance: 9,999 μF
Accuracy: ±(1%+2)
Maximum resolution: 0.01 nF
- Frequency
Maximum frequency: 200 kHz
Accuracy: ±(0,005%+1)
Maximum resolution: 0.01 Hz
- Operating cycle
Maximum operating cycle: 99,9%
Accuracy: ±(0.2%/KHz +0.1%)
Maximum resolution: 0,1%
- Temperature measurement
Fluke 87 V, 87 V/E: -200.0°C – 1090°C
- Diodes
Measuring range: 3V
Resolution: 1 mV
Accuracy: ± (2% + 1)
- Operating cycle range
Accuracy: Within ± (0.2%/kHz + 0.1 %)
